CW Series Temperature Controllers (Water) |
| The CW series water temperature controllers use water as the heating medium, and processes under direct cooling method for heating up to 140ºC, with the indirect-cooled “high temperature” type up to 180ºC. |
| |
|
|
Other standard features include:
- All pumps are manufactured from corrosion-free phosphor bronze by “Speck” in Germany.
- Standard control accurate +/– 0.5ºC. (Custom design options also available.)
- The module design is compact, economical, efficient and basically maintenance-free.
- Comes complete with safety protection and error indication system.
- Hot water piping is provided with a single structure formation, extended to 4 inlet and 4 outlet separation tubes to avoid water leakage.
- Rapid heating and cooling off speeds – temperature is kept stable at all times.
- Electical circuit built to comply with CE safety requirements.
|
 |
| |
|
|
|
|
