CSL-DS Large Heavy Duty Dual Shaft Shredder

CSL-DS Large Heavy Duty Dual Shaft Shredder

CSL-DS Large Heavy Duty Dual Shaft Shredder

Download Brochure
Introduction

Comet’s CSL-DS series dual shaft shredders are designed for continuous shredding of large quantities and volumes or when pre-shredding is required for further procedures. The design is based on a proven rotor-shearing/cutting principle – material is captured by the knife hooks, pulled in, and cut between the blades of the two opposing shafts. The two powerful cutting rotors can handle all materials, even those that are difficult to shred or are bulky and voluminous. Due to its slow rotation speed and high torque, the CSL-DS works at low noise and dust levels while achieving high throughput rates.

Features
  • Economical, rugged, low maintenance design using the proven rotor-shearing/cutting principle.
  • Low power consumption and noise levels without creating dust and flying particles.
  • Blades are manufactured from high quality steel, suitable for shredding tough materials and for extra long life.
  • Side barrier walls and seals prevent fines, dirt, and dust from entering the bearings and gearboxes.
  • Two piece, split bearing housing arrangement enables quick access to bearings and rotor.
  • Shock absorbing gearbox mounting arrangement reduces stress on drive components.
  • Adjustable sealing system prevents product migration and ensures a long bearing service life.
  • Segmented shredding chamber floor with brass guides and PU slides.
  • Stand alone electrical control panel with Siemens PLC control system.
  • Auto reverse system for overload protection that automatically stops and reverses the shredding action in the event of a system overload.
Typical Applications
  • Plastics: purgings and films, extruded sheets, plastic drums, containers, truck and car tires
  • Electronic Waste & Scrap: components, subassemblies & consumables
  • Waste: production, medical, organic
  • Wood: pallets, scrap wood
  • Paper & Packaging Materials: paper/cardboard, books, confidential documents
  • Metals: lead, aluminum, copper, cable, barrels, sheet scrap
  • Textiles: rags, garments, carpet

CSL-DS Large Heavy Duty Dual Shaft Shredder

Options

CSL-DS Large Heavy Duty Dual Shaft Shredder
